PXP-6-50 (1PH/TEFC) BOOSTER PUMP

Booster Pump PXP-6-50 – 650-3010

MODEL NUMBER EXPLANATION:

PXP : Series

6 : G.P.M.

50 : H.P. (1/2)

PUMP:

• The head and motor support are made of stainless steel
• Inlet: 6-10-15-25 GPM = 1 1/4 »
• Inlet: 35-50-80 GPM = 1 1/2 »
• Outlet: 1 1/4 »

MOTOR:

• 1/2 H.P. to 2 H.P. motor – 115/230 Volts – 1 Phase – ODP
• 3 & 5 H.P. motor – 230 Volts – 1 Phase – ODP

*Other voltages and TEFC available as options

FEATURES:

• New high-performance diffusers made of temperature shock-resistant nylon fibers
• Threaded tube for easier repair and maintenance
• Upper support: rubber sleeve for better resistance to dry running
• 304 stainless steel head
• Ultra-resistant interstage bushings with high abrasion resistance and a bearing system at each stage reducing pressure loss
• Polished stainless steel floating disc that reduces friction and dissipates heat
• Color-coded impeller for quick identification of 6 GPM, 10 GPM, 15 GPM and 25 GPM pumps
